Honda Engine For S-TMCT60PH Rammer

Description

• The Honda GX100 is a compact, high‑performance petrol engine designed to power the S‑TMCT60PH Rammer. Built with 4‑stroke, overhead valve technology, it delivers reliable output with excellent fuel efficiency. Its lightweight design, transistorised magneto ignition, and recoil start system make it easy to operate, while the forced‑air cooling system ensures durability in demanding construction environments.


  Key Features

  • Model: GX100 – Honda’s proven small engine series.
  • Type: 4‑stroke, OHV, single‑cylinder, horizontal shaft.
  • Bore & Stroke: 56 × 40 mm.
  • Displacement: 98 cm³.
  • Compression Ratio: 8.5:1 – efficient combustion.
  • Continuous Rated Power: 1.7 kW (2.3 HP) at 3,600 rpm.
  • Maximum Net Torque: 5.7 Nm at 2,500 rpm.
  • Ignition System: Transistorised magneto – reliable spark.
  • Starting System: Recoil – simple and dependable.
  • Cooling System: Forced‑air – prevents overheating.
  • PTO Shaft Rotation: Counter‑clockwise (from P.T.O. side).
  • Fuel Consumption: 0.88 L/h at rated power (3,600 rpm).
  • Fuel Tank Capacity: 0.77 L – compact yet efficient.
  • Oil Capacity: 0.4 L (recommended 10W/30 API SJ).
  • Dimensions: 295 × 304 × 402 mm.
  • Dry Weight: 10.63 kg – lightweight and portable.

  Benefits

  • Compact and lightweight for easy integration into rammers.
  • Reliable Honda engineering ensures long service life.
  • Low fuel consumption reduces operating costs.
  • Easy recoil start and transistorized ignition for quick operation.

Lead time: Estimate of 3-5 Working days depending on stock availability
